Product Advantage:

• Si3N4 silicon nitride ceramic balls
  High hardness, high moisture resistance, wear resistance, low friction coefficient, low-temperature rise. The long-term use temperature can reach 1400℃.
• Special metal cage
  Special metal containing nickel is used to withstand high temperatures. Long-term use temperature up to 600℃, instantaneous temperature up to 800℃.
• PEEK + GF cage
  It has the characteristics of high-temperature resistance and self-lubrication, and because of its lightweight, it has little influence on the vibration and dynamic balance caused by the rotation of the bearing, so it is very suitable for use at high speed.
  Long-term use temperature up to 300℃, limiting temperature up to 380℃.





HP5.218G34.2                                                                             Inner range: 6mm, Outer range: 18mm, Height: 34.2mm

Apply to GT17/GT20/GT25                                                            Cage is optional：PEEK, Brass, Special metal cage

Basically, the outside diameter step is used for positioning. If there are other positioning methods, please consult us

Limit speed 180000r/m; limiting temperature 600 ℃





HP60G01                                                                                      Inner range: 8mm, Outer range: 22mm, Height: 53.73mm

Apply to GT25R/GT28R/GT30R/GT35R                                    Cage is optional：PEEK, Brass, Special metal cage

The basic model is positioned with a 6mm positioning pin. If there are other positioning methods, please consult us

Limit speed 150000r/m; limiting temperature 600 ℃





HP0822G07                                                                                 Inner range: 8mm, Outer range: 22mm, Height: 41.95mm

Apply to GT25R/GT28R/GT30R/GT35R                                    Cage is optional：PEEK, Brass, Special metal cage

The basic model is positioned with a 6mm positioning pin. If there are other positioning methods, please consult us

Limit speed 150000r/m; limiting temperature 600 ℃





HP1028G03                                                                                 Inner range: 10mm, Outer range: 28.2mm, Height: 55.2mm

Apply to GTX37/GTX40/GTX42/GTX45                                    Cage is optional：PEEK, Brass, Special metal cage

The basic model is positioned with an 8mm positioning pin. If there are other positioning methods, please consult us

Limit speed 120000r/m; limiting temperature 600 ℃





HP1028G05                                                                                 Inner range: 10mm, Outer range: 28.2mm, Height: 44.55mm

Apply to GTX37/GTX40/GTX42/GTX45                                    Cage is optional：PEEK, Brass, Special metal cage

With two grooves of outer diameter as positioning, the oil outlet is a 1-word hole

Limit speed 100000r/m; limiting temperature 600 ℃





HP1335G01                                                                                 Inner range: 13mm, Outer range: 34.8mm, Height: 64.08mm

Apply to GTX42/GTX45                                                                 Cage is optional：PEEK, Brass, Special metal cage

The basic model is positioned with an 8mm positioning pin. If there are other positioning methods, please consult us

Limit speed 80000r/m; limiting temperature 600 ℃



Except for turbocharger bearings, XEZ also supplies other precision ball bearings, range from 6-150mm, please contact our sales team for a sample or quotation.

XEZ History

Since its establishment in 1988, XEZ has been a private Sci-Tech enterprise, engaging in the production of high-precision bearing. Currently, XEZ mainly produces precision angular contact ball bearing, deep groove ball bearing, and double row cylindrical roller bearing, which are mainly applied to CNC machine tool spindle, turbocharger, vacuum pump, and other precision machinery.

XEZ factory occupied area 29001㎡, has more than 340 staff.

Annual value of production: 43,000,000USD.

More than 60 production lines for precision ball bearing.

Main Equipment Deep groove ball bearing: 27 lines Angular contact ball bearing: 20 lines

Parallel surface grinder: 9 sets, centerless grinder: 9 sets Auto inner core grinder: 50 sets, auto inner groove grinder: 50 sets High precise flat grinder: 10 sets Inner/outer groove superfinishing machine: 115 sets Automatic grease injection and capping machine: 27 sets Bearing testing equipment: 10 sets
